Box External Dimensions Width × Height × Depth |
36.00" × 16.00" × 14.49" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.00 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 36 inch2 |
| Port Inlet Width × Height |
2.48" × 14.50" |
| Port Length | 24.22" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 36.00" × 14.49" | 2 |
| Front | 32.77" × 14.50" | 1 |
| Rear | 36.00" × 14.50" | 1 |
| Left | 12.99" × 14.50" | 1 |
| Right | 13.74" × 14.50" | 1 |
| Port | 10.51" × 14.50" | 1 |
| Port | 9.73" × 14.50" | 1 |
