Subwoofer Box for Pride Pride LP 12

Ported Box for 12 inch Subwoofer


Box External Dimensions
Width × Height × Depth
23.23" × 15.39" × 15.48"
Material Thickness 0.71"
Net Internal Volume 1.94 ft3
Tuning Frequency 35 Hz
Port Area 27.12 inch2
Port Inlet
Width × Height
1.94" × 13.98"
Port Length 24.35"


Detail Size Quantity
Top / Bottom 23.23" × 15.48" 2
Front 20.58" × 13.98" 1
Rear 23.23" × 13.98" 1
Left 14.07" × 13.98" 1
Right 14.78" × 13.98" 1
Port 12.13" × 13.98" 1
Port 8.86" × 13.98" 1
Ø282mm 23.23" 20.58" 15.48" 14.07" 15.48" 14.07" 15.39" 13.98" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
