Box External Dimensions Width × Height × Depth |
19.69" × 11.81" × 8.93" |
| Material Thickness | 0.63" |
| Net Internal Volume | 0.81 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 5.4 inch2 |
| Port Inlet Width × Height |
0.52" × 10.55" |
| Port Length | 11.84" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 8.93" | 2 |
| Front | 18.54" × 10.55" | 1 |
| Rear | 19.69" × 10.55" | 1 |
| Left | 7.67" × 10.55" | 1 |
| Right | 8.30" × 10.55" | 1 |
| Port | 7.16" × 10.55" | 1 |
| Port | 2.91" × 10.55" | 1 |
