Subwoofer Box for Pride Junior Pro 12

Ported Box for 12 inch Subwoofer


Box External Dimensions
Width x Height x Depth
26.77" x 13.78" x 13.90"
Material Thickness 0.63"
Net Internal Volume 1.94 ft3
Tuning Frequency 35 Hz
Port Area 23.25 inch2
Port Inlet
Width x Height
1.86" x 12.52"
Port Length 20.43"


Detail Size Quantity
Top / Bottom 26.77" x 13.90" 2
Front 24.28" x 12.52" 1
Rear 26.77" x 12.52" 1
Left 12.64" x 12.52" 1
Right 13.27" x 12.52" 1
Port 10.78" x 12.52" 1
Port 6.53" x 12.52" 1
Ø284mm 26.77" 24.28" 13.90" 12.64" 13.90" 12.64" 13.78" 12.52" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
