Box External Dimensions Width × Height × Depth |
17.72" × 7.87" × 15.29" |
| Material Thickness | 0.63" |
| Net Internal Volume | 0.71 ft3 |
| Tuning Frequency | 28 Hz |
| Port Area | 6.2 inch2 |
| Port Inlet Width × Height |
0.94" × 6.61" |
| Port Length | 27.11" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 17.72" × 15.29" | 2 |
| Front | 16.15" × 6.61" | 1 |
| Rear | 17.72" × 6.61" | 1 |
| Left | 14.03" × 6.61" | 1 |
| Right | 14.66" × 6.61" | 1 |
| Port | 13.09" × 6.61" | 1 |
| Port | 11.82" × 6.61" | 1 |
