Box External Dimensions Width × Height × Depth |
45.00" × 8.00" × 14.13" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.05 ft3 |
| Tuning Frequency | 45 Hz |
| Port Area | 36 inch2 |
| Port Inlet Width × Height |
5.54" × 6.50" |
| Port Length | 38.32" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 45.00" × 14.13" | 2 |
| Front | 38.72" × 6.50" | 1 |
| Rear | 45.00" × 6.50" | 1 |
| Left | 12.63" × 6.50" | 1 |
| Right | 13.38" × 6.50" | 1 |
| Port | 7.10" × 6.50" | 1 |
| Port | 24.19" × 6.50" | 1 |
