Box External Dimensions Width × Height × Depth |
30.71" × 13.78" × 15.09" |
| Material Thickness | 0.59" |
| Net Internal Volume | 2.68 ft3 |
| Tuning Frequency | 36.6 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.85" × 12.60" |
| Port Length | 11.53" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.71" × 15.09" | 2 |
| Front | 28.27" × 12.60" | 1 |
| Rear | 30.71" × 12.60" | 1 |
| Left | 13.91" × 12.60" | 1 |
| Right | 14.50" × 12.60" | 1 |
| Port | 10.94" × 12.60" | 1 |
