Box External Dimensions Width × Height × Depth |
35.43" × 14.37" × 18.50" |
| Material Thickness | 0.71" |
| Net Internal Volume | 3.35 ft3 |
| Tuning Frequency | 28 Hz |
| Port Area | 38.8 inch2 |
| Port Inlet Width × Height |
2.99" × 12.95" |
| Port Length | 32.08" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 18.50" | 2 |
| Front | 31.73" × 12.95" | 1 |
| Rear | 35.43" × 12.95" | 1 |
| Left | 17.08" × 12.95" | 1 |
| Right | 17.79" × 12.95" | 1 |
| Port | 14.09" × 12.95" | 1 |
| Port | 13.58" × 12.95" | 1 |
