Subwoofer Box for Skar DDX-15

Ported Box for 15 inch Subwoofer


Box External Dimensions
Width x Height x Depth
31.50" x 17.72" x 19.86"
Material Thickness 0.71"
Net Internal Volume 3.99 ft3
Tuning Frequency 36 Hz
Port Area 64.32 inch2
Port Inlet
Width x Height
3.94" x 16.30"
Port Length 25.80"

Top Panel:

Detail Size Quantity
Top / Bottom 31.50" x 19.86" 2
Front 26.84" x 16.30" 1
Rear 31.50" x 16.30" 1
Left 18.44" x 16.30" 1
Right 19.15" x 16.30" 1
Port 14.50" x 16.30" 1
Port 9.88" x 16.30" 1
Ø354.8mm 31.50" 26.84" 19.86" 18.44" 19.86" 18.44" 17.72" 16.30" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
