Box External Dimensions Width × Height × Depth |
19.69" × 14.57" × 16.36" |
| Material Thickness | 0.71" |
| Net Internal Volume | 1.62 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.77" × 13.15" |
| Port Length | 22.27" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 16.36" | 2 |
| Front | 17.21" × 13.15" | 1 |
| Rear | 19.69" × 13.15" | 1 |
| Left | 14.94" × 13.15" | 1 |
| Right | 15.65" × 13.15" | 1 |
| Port | 13.17" × 13.15" | 1 |
| Port | 5.91" × 13.15" | 1 |
