Box External Dimensions Width × Height × Depth |
36.00" × 17.25" × 25.00" |
| Material Thickness | 0.75" |
| Net Internal Volume | 5.41 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 86.6 inch2 |
| Port Inlet Width × Height |
5.50" × 15.76" |
| Port Length | 30.76" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 36.00" × 25.00" | 2 |
| Front | 29.75" × 15.76" | 1 |
| Rear | 36.00" × 15.76" | 1 |
| Left | 23.51" × 15.76" | 1 |
| Right | 24.26" × 15.76" | 1 |
| Port | 18.01" × 15.76" | 1 |
| Port | 5.76" × 15.76" | 1 |
