Box External Dimensions Width × Height × Depth |
20.00" × 9.00" × 11.05" |
| Material Thickness | 0.60" |
| Net Internal Volume | 0.74 ft3 |
| Tuning Frequency | 45 Hz |
| Port Area | 10 inch2 |
| Port Inlet Width × Height |
1.28" × 7.80" |
| Port Length | 14.07" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 20.00" × 11.05" | 2 |
| Front | 18.12" × 7.80" | 1 |
| Rear | 20.00" × 7.80" | 1 |
| Left | 9.85" × 7.80" | 1 |
| Right | 10.45" × 7.80" | 1 |
| Port | 8.57" × 7.80" | 1 |
| Port | 3.02" × 7.80" | 1 |
