Box External Dimensions Width × Height × Depth |
39.00" × 22.00" × 22.36" |
| Material Thickness | 0.71" |
| Net Internal Volume | 6.90 ft3 |
| Tuning Frequency | 22 Hz |
| Port Area | 72 inch2 |
| Port Inlet Width × Height |
3.50" × 20.58" |
| Port Length | 47.70" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 39.00" × 22.36" | 2 |
| Front | 34.79" × 20.58" | 1 |
| Rear | 39.00" × 20.58" | 1 |
| Left | 20.94" × 20.58" | 1 |
| Right | 21.65" × 20.58" | 1 |
| Port | 17.44" × 20.58" | 1 |
| Port | 25.34" × 20.58" | 1 |
