Box External Dimensions Width × Height × Depth |
58.00" × 13.00" × 13.78" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.00 ft3 |
| Tuning Frequency | 28 Hz |
| Port Area | 38.3 inch2 |
| Port Inlet Width × Height |
3.33" × 11.50" |
| Port Length | 58.30" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 58.00" × 13.78" | 2 |
| Front | 53.92" × 11.50" | 1 |
| Rear | 58.00" × 11.50" | 1 |
| Left | 12.29" × 11.50" | 1 |
| Right | 13.04" × 11.50" | 1 |
| Port | 8.96" × 11.50" | 1 |
| Port | 44.51" × 11.50" | 1 |
