Box External Dimensions Width × Height × Depth |
30.00" × 14.00" × 31.23" |
| Material Thickness | 0.63" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 25 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.83" × 12.74" |
| Port Length | 10.81" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 30.00" × 31.23" | 2 |
| Front | 27.54" × 12.74" | 1 |
| Rear | 30.00" × 12.74" | 1 |
| Left | 29.97" × 12.74" | 1 |
| Right | 30.60" × 12.74" | 1 |
| Port | 10.19" × 12.74" | 1 |
