Box External Dimensions Width × Height × Depth |
32.68" × 19.69" × 12.99" |
| Material Thickness | 0.79" |
| Net Internal Volume | 3.14 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 38.8 inch2 |
| Port Inlet Width × Height |
2.14" × 18.11" |
| Port Length | 18.03" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 32.68" × 12.99" | 2 |
| Front | 29.75" × 18.11" | 1 |
| Rear | 32.68" × 18.11" | 1 |
| Left | 11.42" × 18.11" | 1 |
| Right | 12.20" × 18.11" | 1 |
| Port | 9.28" × 18.11" | 1 |
| Port | 5.04" × 18.11" | 1 |
