Box External Dimensions Width × Height × Depth |
23.62" × 15.75" × 14.18" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 60 Hz |
| Port Area | 28.7 inch2 |
| Pipe Inner Diameter | 6.05" |
| Pipe Length | 3.43" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.62" × 14.18" | 2 |
| Front / Rear | 23.62" × 14.49" | 2 |
| Left / Right | 12.92" × 14.49" | 2 |
