Box External Dimensions Width × Height × Depth |
40.00" × 20.00" × 19.71" |
| Material Thickness | 0.75" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 84 inch2 |
| Port Inlet Width × Height |
4.54" × 18.50" |
| Port Length | 19.60" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 40.00" × 19.71" | 2 |
| Front / Rear | 40.00" × 18.50" | 2 |
| Left | 18.22" × 18.50" | 1 |
| Right | 12.93" × 18.50" | 1 |
| Port | 19.60" × 18.50" | 1 |
