Subwoofer Box Specifications
Enclosure Name: Mw12d
Subwoofer Brand: DLS
Subwoofer Size: 12 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
19.69" × 15.75" × 22.61" |
| Material Thickness | 0.87" |
| Net Internal Volume | 2.12 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 38.8 inch2 |
| Port Inlet Width × Height |
2.76" × 14.02" |
| Port Length | 32.61" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 22.61" | 2 |
| Front | 16.06" × 14.02" | 1 |
| Rear | 19.69" × 14.02" | 1 |
| Left | 20.88" × 14.02" | 1 |
| Right | 21.74" × 14.02" | 1 |
| Port | 18.11" × 14.02" | 1 |
| Port | 10.00" × 14.02" | 1 |
