Box External Dimensions Width × Height × Depth |
35.43" × 21.26" × 29.33" |
| Material Thickness | 0.79" |
| Net Internal Volume | 8.83 ft3 |
| Tuning Frequency | 24 Hz |
| Port Area | 76.0 inch2 |
| Pipe Inner Diameter | 9.84" |
| Pipe Length | 30.62" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 29.33" | 2 |
| Front / Rear | 35.43" × 19.69" | 2 |
| Left / Right | 27.76" × 19.69" | 2 |
