Box External Dimensions Width × Height × Depth |
22.87" × 19.75" × 21.43" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.75 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 42 inch2 |
| Port Inlet Width × Height |
2.30" × 18.26" |
| Port Length | 23.48" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 22.87" × 21.43" | 2 |
| Front | 19.83" × 18.26" | 1 |
| Rear | 22.87" × 18.26" | 1 |
| Left | 19.93" × 18.26" | 1 |
| Right | 20.68" × 18.26" | 1 |
| Port | 17.63" × 18.26" | 1 |
| Port | 2.05" × 18.26" | 1 |
