Box External Dimensions Width × Height × Depth |
29.53" × 15.75" × 11.85" |
| Material Thickness | 0.79" |
| Net Internal Volume | 1.94 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.64" × 14.17" |
| Port Length | 20.43" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 29.53" × 11.85" | 2 |
| Front | 27.10" × 14.17" | 1 |
| Rear | 29.53" × 14.17" | 1 |
| Left | 10.28" × 14.17" | 1 |
| Right | 11.06" × 14.17" | 1 |
| Port | 8.63" × 14.17" | 1 |
| Port | 8.58" × 14.17" | 1 |
