Subwoofer Box Specifications
Enclosure Name: S-W12D4 Ported
Subwoofer Brand: Alpine
Subwoofer Size: 12 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
23.00" × 14.00" × 12.86" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.50 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 12.5 inch2 |
| Port Inlet Width × Height |
1.00" × 12.50" |
| Port Length | 20.61" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.00" × 12.86" | 2 |
| Front | 21.25" × 12.50" | 1 |
| Rear | 23.00" × 12.50" | 1 |
| Left | 11.36" × 12.50" | 1 |
| Right | 12.11" × 12.50" | 1 |
| Port | 10.36" × 12.50" | 1 |
| Port | 7.75" × 12.50" | 1 |
