Box External Dimensions Width × Height × Depth |
22.00" × 18.00" × 26.67" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.20 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 64 inch2 |
| Port Inlet Width × Height |
3.88" × 16.50" |
| Port Length | 36.84" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 22.00" × 26.67" | 2 |
| Front | 17.37" × 16.50" | 1 |
| Rear | 22.00" × 16.50" | 1 |
| Left | 25.18" × 16.50" | 1 |
| Right | 25.93" × 16.50" | 1 |
| Port | 21.30" × 16.50" | 1 |
| Port | 10.17" × 16.50" | 1 |
