Box External Dimensions Width × Height × Depth |
13.78" × 16.93" × 19.51" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.01 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 12.2 inch2 |
| Pipe Inner Diameter | 3.94" |
| Pipe Length | 8.70" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 13.78" × 19.51" | 2 |
| Front / Rear | 13.78" × 15.67" | 2 |
| Left / Right | 18.25" × 15.67" | 2 |
