Box External Dimensions Width × Height × Depth |
34.25" × 12.60" × 7.56" |
| Material Thickness | 0.63" |
| Net Internal Volume | 1.06 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 14.8 inch2 |
| Pipe Inner Diameter | 3.07" |
| Pipe Length | 31.66" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 34.25" × 7.56" | 2 |
| Front / Rear | 34.25" × 11.34" | 2 |
| Left / Right | 6.30" × 11.34" | 2 |
