Box External Dimensions Width × Height × Depth |
32.00" × 13.50" × 19.70" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.75 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 44 inch2 |
| Port Inlet Width × Height |
3.67" × 12.00" |
| Port Length | 33.97" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 32.00" × 19.70" | 2 |
| Front | 27.59" × 12.00" | 1 |
| Rear | 32.00" × 12.00" | 1 |
| Left | 18.20" × 12.00" | 1 |
| Right | 18.95" × 12.00" | 1 |
| Port | 14.54" × 12.00" | 1 |
| Port | 14.28" × 12.00" | 1 |
