Box External Dimensions Width × Height × Depth |
19.69" × 12.20" × 12.54" |
| Material Thickness | 0.71" |
| Net Internal Volume | 1.01 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 14.0 inch2 |
| Port Inlet Width × Height |
1.29" × 10.79" |
| Port Length | 24.24" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 19.69" × 12.54" | 2 |
| Front | 17.69" × 10.79" | 1 |
| Rear | 19.69" × 10.79" | 1 |
| Left | 11.12" × 10.79" | 1 |
| Right | 11.83" × 10.79" | 1 |
| Port | 9.83" × 10.79" | 1 |
| Port | 11.70" × 10.79" | 1 |
