Box External Dimensions Width × Height × Depth |
17.32" × 11.02" × 12.16" |
| Material Thickness | 0.71" |
| Net Internal Volume | 0.92 ft3 |
| Tuning Frequency | 36 Hz |
| Port Area | 3.8 inch2 |
| Pipe Inner Diameter | 2.20" |
| Pipe Length | 6.47" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 17.32" × 12.16" | 2 |
| Front / Rear | 17.32" × 9.61" | 2 |
| Left / Right | 10.74" × 9.61" | 2 |
