Subwoofer Box 20hz 10"

Ported Box for 10 inch Subwoofer


10 inch subwoofer box 20hz 10"

Subwoofer Box Specifications

Enclosure Name: 20hz 10"

Subwoofer Size: 10 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
25.59" × 25.59" × 26.52"
Material Thickness 0.71"
Net Internal Volume 7.06 ft3
Tuning Frequency 19.7 Hz
Port Area 46.5 inch2
Port Inlet
Width × Height
1.93" × 24.17"
Port Length 37.36"


Detail Size Quantity
Top / Bottom 25.59" × 26.52" 2
Front 22.96" × 24.17" 1
Rear 25.59" × 24.17" 1
Left 25.11" × 24.17" 1
Right 25.81" × 24.17" 1
Port 23.18" × 24.17" 1
Port 10.84" × 24.17" 1
Ø237mm 25.59" 22.96" 26.52" 25.11" 26.52" 25.11" 25.59" 24.17" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
