Subwoofer Box Specifications
Enclosure Name: EVL 12 D2
Subwoofer Brand: Skar Audio
Subwoofer Size: 12 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
28.00" × 16.00" × 15.00" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.02 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 36.3 inch2 |
| Port Inlet Width × Height |
2.50" × 14.50" |
| Port Length | 34.46" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 28.00" × 15.00" | 2 |
| Front | 24.75" × 14.50" | 1 |
| Rear | 28.00" × 14.50" | 1 |
| Left | 13.50" × 14.50" | 1 |
| Right | 14.25" × 14.50" | 1 |
| Port | 11.00" × 14.50" | 1 |
| Port | 19.46" × 14.50" | 1 |
