Subwoofer Box Specifications
Enclosure Name: 12
Subwoofer Brand: Fusion
Subwoofer Size: 12 inch
Subwoofer Count: 1
|
Box External Dimensions Width × Height × Depth |
23.62" × 13.78" × 17.42" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.30 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.86" × 12.52" |
| Port Length | 16.38" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 23.62" × 17.42" | 2 |
| Front | 21.13" × 12.52" | 1 |
| Rear | 23.62" × 12.52" | 1 |
| Left | 16.16" × 12.52" | 1 |
| Right | 16.79" × 12.52" | 1 |
| Port | 13.67" × 12.52" | 1 |
