Box External Dimensions Width × Height × Depth |
45.00" × 22.00" × 18.83" |
| Material Thickness | 1.00" |
| Net Internal Volume | 5.25 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 78 inch2 |
| Port Inlet Width × Height |
3.90" × 20.00" |
| Port Length | 21.88" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 45.00" × 18.83" | 2 |
| Front | 40.10" × 20.00" | 1 |
| Rear | 45.00" × 20.00" | 1 |
| Left | 16.83" × 20.00" | 1 |
| Right | 17.83" × 20.00" | 1 |
| Port | 12.93" × 20.00" | 1 |
| Port | 3.05" × 20.00" | 1 |
