Box External Dimensions Width × Height × Depth |
26.00" × 23.00" × 16.56" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.50 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 23.2 inch2 |
| Pipe Inner Diameter | 5.44" |
| Pipe Length | 7.43" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 26.00" × 16.56" | 2 |
| Front / Rear | 26.00" × 21.50" | 2 |
| Left / Right | 15.06" × 21.50" | 2 |
