Box External Dimensions Width × Height × Depth |
45.00" × 15.00" × 17.06" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.50 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 38 inch2 |
| Port Inlet Width × Height |
2.81" × 13.50" |
| Port Length | 12.16" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 45.00" × 17.06" | 2 |
| Front | 41.44" × 13.50" | 1 |
| Rear | 45.00" × 13.50" | 1 |
| Left | 15.56" × 13.50" | 1 |
| Right | 16.31" × 13.50" | 1 |
| Port | 11.41" × 13.50" | 1 |
