Box External Dimensions Width × Height × Depth |
47.75" × 37.75" × 26.78" |
| Material Thickness | 1.00" |
| Net Internal Volume | 16.00 ft3 |
| Tuning Frequency | 25 Hz |
| Port Area | 240 inch2 |
| Port Inlet Width × Height |
6.71" × 35.75" |
| Port Length | 45.73" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 47.75" × 26.78" | 2 |
| Front | 40.04" × 35.75" | 1 |
| Rear | 47.75" × 35.75" | 1 |
| Left | 24.78" × 35.75" | 1 |
| Right | 25.78" × 35.75" | 1 |
| Port | 18.06" × 35.75" | 1 |
| Port | 18.96" × 35.75" | 1 |
