Box External Dimensions Width × Height × Depth |
40.00" × 14.00" × 20.26" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 64 inch2 |
| Port Inlet Width × Height |
5.12" × 12.50" |
| Port Length | 29.80" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 40.00" × 20.26" | 2 |
| Front | 34.13" × 12.50" | 1 |
| Rear | 40.00" × 12.50" | 1 |
| Left | 18.76" × 12.50" | 1 |
| Right | 19.51" × 12.50" | 1 |
| Port | 13.64" × 12.50" | 1 |
| Port | 9.54" × 12.50" | 1 |
