Box External Dimensions Width × Height × Depth |
26.00" × 9.00" × 19.85" |
| Material Thickness | 0.75" |
| Net Internal Volume | 1.50 ft3 |
| Tuning Frequency | 40 Hz |
| Port Area | 16 inch2 |
| Port Inlet Width × Height |
2.13" × 7.50" |
| Port Length | 13.06" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 26.00" × 19.85" | 2 |
| Front / Rear | 26.00" × 7.50" | 2 |
| Left | 18.36" × 7.50" | 1 |
| Right | 15.48" × 7.50" | 1 |
| Port | 13.06" × 7.50" | 1 |
