Subwoofer Box 8inch

Ported Box for 8 inch Subwoofer


8 inch subwoofer box 8inch

Subwoofer Box Specifications

Enclosure Name: 8inch

Subwoofer Size: 8 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
13.50" × 12.00" × 17.43"
Material Thickness 0.75"
Net Internal Volume 1.00 ft3
Tuning Frequency 36 Hz
Port Area 10 inch2
Port Inlet
Width × Height
0.95" × 10.50"
Port Length 16.93"


Detail Size Quantity
Top / Bottom 13.50" × 17.43" 2
Front 11.80" × 10.50" 1
Rear 13.50" × 10.50" 1
Left 15.93" × 10.50" 1
Right 16.68" × 10.50" 1
Port 14.23" × 10.50" 1
Ø188mm 13.50" 11.80" 17.43" 15.93" 17.43" 15.93" 12.00" 10.50" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
