Box External Dimensions Width × Height × Depth |
27.56" × 22.05" × 22.46" |
| Material Thickness | 0.71" |
| Net Internal Volume | 6.00 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 43.4 inch2 |
| Port Inlet Width × Height |
2.10" × 20.63" |
| Port Length | 7.86" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 27.56" × 22.46" | 2 |
| Front | 24.75" × 20.63" | 1 |
| Rear | 27.56" × 20.63" | 1 |
| Left | 21.04" × 20.63" | 1 |
| Right | 21.75" × 20.63" | 1 |
| Port | 7.15" × 20.63" | 1 |
