Box External Dimensions Width × Height × Depth |
35.43" × 18.90" × 20.11" |
| Material Thickness | 0.79" |
| Net Internal Volume | 4.24 ft3 |
| Tuning Frequency | 25 Hz |
| Port Area | 54.3 inch2 |
| Port Inlet Width × Height |
3.13" × 17.32" |
| Port Length | 46.17" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 20.11" | 2 |
| Front | 31.52" × 17.32" | 1 |
| Rear | 35.43" × 17.32" | 1 |
| Left | 18.54" × 17.32" | 1 |
| Right | 19.32" × 17.32" | 1 |
| Port | 15.41" × 17.32" | 1 |
| Port | 26.06" × 17.32" | 1 |
