Box External Dimensions Width × Height × Depth |
35.43" × 16.14" × 14.92" |
| Material Thickness | 0.71" |
| Net Internal Volume | 3.18 ft3 |
| Tuning Frequency | 34 Hz |
| Port Area | 40.6 inch2 |
| Port Inlet Width × Height |
2.76" × 14.72" |
| Port Length | 21.97" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 35.43" × 14.92" | 2 |
| Front | 31.97" × 14.72" | 1 |
| Rear | 35.43" × 14.72" | 1 |
| Left | 13.50" × 14.72" | 1 |
| Right | 14.21" × 14.72" | 1 |
| Port | 10.74" × 14.72" | 1 |
| Port | 7.06" × 14.72" | 1 |
