Box External Dimensions Width × Height × Depth |
20.00" × 15.50" × 19.97" |
| Material Thickness | 1.00" |
| Net Internal Volume | 2.00 ft3 |
| Tuning Frequency | 30 Hz |
| Port Area | 21.7 inch2 |
| Port Inlet Width × Height |
1.61" × 13.50" |
| Port Length | 26.80" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 20.00" × 19.97" | 2 |
| Front | 17.39" × 13.50" | 1 |
| Rear | 20.00" × 13.50" | 1 |
| Left | 17.97" × 13.50" | 1 |
| Right | 18.97" × 13.50" | 1 |
| Port | 16.37" × 13.50" | 1 |
| Port | 6.83" × 13.50" | 1 |
