Box External Dimensions Width × Height × Depth |
22.44" × 14.17" × 16.00" |
| Material Thickness | 0.71" |
| Net Internal Volume | 1.77 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.82" × 12.76" |
| Port Length | 28.74" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 22.44" × 16.00" | 2 |
| Front | 19.91" × 12.76" | 1 |
| Rear | 22.44" × 12.76" | 1 |
| Left | 14.58" × 12.76" | 1 |
| Right | 15.29" × 12.76" | 1 |
| Port | 12.76" × 12.76" | 1 |
| Port | 12.74" × 12.76" | 1 |
