Subwoofer Box Machete M10D4

Ported Box for 10 inch Subwoofer


10 inch subwoofer box Machete M10D4

Subwoofer Box Specifications

Enclosure Name: M10D4

Subwoofer Brand: Machete

Subwoofer Size: 10 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
21.65" × 12.60" × 12.87"
Material Thickness 0.63"
Net Internal Volume 1.41 ft3
Tuning Frequency 37 Hz
Port Area 10.8 inch2
Pipe Inner Diameter 3.70"
Pipe Length 11.34"


Detail Size Quantity
Top / Bottom 21.65" × 12.87" 2
Front / Rear 21.65" × 11.34" 2
Left / Right 11.61" × 11.34" 2
Ø100mm Ø230mm 21.65" 12.87" 11.61" 12.87" 11.61" 12.60" 11.34" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
