Box External Dimensions Width × Height × Depth |
20.00" × 15.00" × 16.04" |
| Material Thickness | 0.63" |
| Net Internal Volume | 2.20 ft3 |
| Tuning Frequency | 60 Hz |
| Port Area | 12.6 inch2 |
| Pipe Inner Diameter | 4.00" |
| Pipe Length | 0.35" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 20.00" × 16.04" | 2 |
| Front / Rear | 20.00" × 13.74" | 2 |
| Left / Right | 14.78" × 13.74" | 2 |
