Box External Dimensions Width × Height × Depth |
36.00" × 16.00" × 22.09" |
| Material Thickness | 0.75" |
| Net Internal Volume | 3.92 ft3 |
| Tuning Frequency | 32 Hz |
| Port Area | 68.5 inch2 |
| Port Inlet Width × Height |
4.72" × 14.50" |
| Port Length | 35.92" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 36.00" × 22.09" | 2 |
| Front | 30.53" × 14.50" | 1 |
| Rear | 36.00" × 14.50" | 1 |
| Left | 20.59" × 14.50" | 1 |
| Right | 21.34" × 14.50" | 1 |
| Port | 15.87" × 14.50" | 1 |
| Port | 13.83" × 14.50" | 1 |
