Subwoofer Box Skar zvx15 4CF@33Hz 2007 VW Jetta

Ported Box for 15 inch Subwoofer


15 inch subwoofer box Skar zvx15 4CF@33Hz 2007 VW Jetta

Subwoofer Box Specifications

Enclosure Name: zvx15 4CF@33Hz 2007 VW Jetta

Subwoofer Brand: Skar

Subwoofer Size: 15 inch

Subwoofer Count: 1

Box External Dimensions
Width × Height × Depth
37.00" × 18.00" × 16.83"
Material Thickness 0.75"
Net Internal Volume 4.00 ft3
Tuning Frequency 33 Hz
Port Area 56.5 inch2
Pipe Inner Diameter 6.00"
Pipe Length 29.04"


Detail Size Quantity
Top / Bottom 37.00" × 16.83" 2
Front / Rear 37.00" × 16.50" 2
Left / Right 15.34" × 16.50" 2
Ø158.8mm Ø158.8mm Ø358.8mm 37.00" 16.83" 15.34" 16.83" 15.34" 18.00" 16.50" Top Top Bottom Bottom Rear Front Left Right Rear Front Left Right subbox.pro
