Box External Dimensions Width × Height × Depth |
33.46" × 18.31" × 18.75" |
| Material Thickness | 0.79" |
| Net Internal Volume | 4.41 ft3 |
| Tuning Frequency | 29 Hz |
| Port Area | 44.9 inch2 |
| Pipe Inner Diameter | 7.56" |
| Pipe Length | 25.12" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 33.46" × 18.75" | 2 |
| Front / Rear | 33.46" × 16.73" | 2 |
| Left / Right | 17.18" × 16.73" | 2 |
