Box External Dimensions Width × Height × Depth |
33.46" × 14.96" × 15.86" |
| Material Thickness | 0.71" |
| Net Internal Volume | 3.50 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 23.3 inch2 |
| Port Inlet Width × Height |
1.72" × 13.54" |
| Port Length | 8.72" |
| Detail | Size | Quantity |
|---|---|---|
| Top / Bottom | 33.46" × 15.86" | 2 |
| Front | 31.04" × 13.54" | 1 |
| Rear | 33.46" × 13.54" | 1 |
| Left | 14.44" × 13.54" | 1 |
| Right | 15.15" × 13.54" | 1 |
| Port | 8.02" × 13.54" | 1 |
